Fluke MDA-510 and MDA-550 Motor Drive Analyzer Product Overview

http://bit.ly/2E5xlqq

Hear from Fluke Product Applications Engineer Han Tran, and Maintenance Manager Mark Newport how the Fluke MDA-500 Series Motor Drive Analyzers are making it easier to troubleshoot variable frequency drives. With dedicated motor drive analysis functionality, built-in tests and visual guidance the Fluke MDA-500 series makes taking measurements on the input of the drive, the DC Bus, the drive output and even the motor shaft simple. whether you're an experienced technician or new to the field.

Designed to simplify complex motor-drive troubleshooting, the MDA-500 Series allows you to simply select the section of the drive you want to troubleshoot, pick a test, and the step-by-step guided measurements will show you where to make connections for both voltage and current so you can be confident that you're getting the right results every time.

- Measure key motor-drive parameters including voltage, current, DC Bus voltage level and AC ripple, voltage and current unbalance and harmonics (MDA-550), voltage modulation, and motor shaft voltage discharges (MDA-550).
- Perform extended harmonics measurements to identify the effects of low and high order harmonics on your electrical power system.
- Conduct guided measurements for motor-drive input, DC bus, drive output, motor input and shaft measurements (MDA-550) with graphical step-by-step voltage and current connection diagrams.
- Use simplified measurement setup with preset measurement profiles to automatically trigger data collection based on the chosen test procedure.
- Create reports quickly and easily that are perfect for documenting troubleshooting and collaborative work with others.
- Measure additional electrical parameters with full 500 MHz oscilloscope, meter and recording capability for complete range of electrical and electronic measurement on industrial systems.

Learn more about how the Fluke MDA-500 Series is simplifying motor drive analysis: http://bit.ly/2E5xlqq
