In this video, learn how to use the Record Mode and how to take temperature measurements using the Fluke 120B Series Industrial ScopeMeter® Handheld Oscilloscope.

Time stamp 0:00: Included/not included accessories and how to hook up the accessories to the instrument

Time stamp 1:46: Meter Recorder Mode. Meter Recorder Mode Trendplots measurements overtime. The Fluke 120B Series Handheld Oscilloscope can record up to 384 hours and can capture up to 1,024 events

Time stamp 1:59 Scope Recorder Mode. Scope Recorder Mode continuously captures waveforms over a period of time. The Fluke 120B Series Portable Oscilloscope can capture up to 64 events and up to 14 days of recording if you have a 32-gig micro SD card inserted.

Time stamp 6:39: Temperature measurement. Fluke temperature modules (sold separately) enhances your Fluke 120B Series Industrial ScopeMeter®, giving you the the flexibility to take temperature measurements.

The compact ScopeMeter® 120B Series, is the rugged oscilloscope solution for industrial electrical and electro-mechanical equipment troubleshooting and maintenance applications. It’s a truly integrated test tool, with oscilloscope, multimeter and high-speed recorder in one easy-to-use instrument. The ScopeMeter 120B Series also integrates with Fluke Connect® mobile app and FlukeView® for ScopeMeter software to enable further collaboration, data analysis and archiving of critical test information.

To learn more about the Fluke 120B Series Industrial ScopeMeter® Handheld Oscilloscope, visit the Fluke website here: http://bit.ly/2Co9Ubl
