Broadcom Smart Gate Drive Optocouplers’ Evolution

Broadcom gate drive optocouplers come in wide range of output current from 0.4A to 10A. These optically-isolated devices are optimized for driving IGBT, Power and SiC/GaN MOSFET, exhibiting rail-to-rail output, fast gate switching speed, high CMR and reinforced insulation. These gate drivers are ideal for use in motor control and power conversion applications where the microcontroller and user need to be isolated and protected from high voltages.

The highly integrated smart gate drive optocouplers provides integrated protection features such as Active Miller Clamp, under voltage lockout, fault and UVLO status feedback and desaturation detection. Broadcom develops reference designs with these smart gate drivers to help customers shorten design cycles and speed up time-to-market. Broadcom has partnered with key industrial players, like IGBT, SiC and GaN suppliers who have in depth system and product knowledge in their respective field, for most of the reference designs
https://www.broadcom.com/products/optocouplers/reference-designs

https://www.broadcom.com/products/optocouplers/industrial-plastic/isolated-gate-drive-optocouplers/highly-integrated-smart-gate-drives/acpl-355jc-000e

*ACPL-355JC-000E*
10A Gate Drive Optocoupler with Integrated FAULT Protection & Feedback in 600V CTI SO16 Package

The ACPL-355JC is a 10A gate drive optocoupler device with an integrated fail-safe IGBT and SiC MOSFET diagnostics, protection and fault reporting. The device features common mode transient immunity (CMTI) greater than 100 kV/μs and provides minimal propagation delay with excellent timing skew. The high peak output current and wide operating voltage range eliminate the need of an output buffer circuit, enabling designers to implement cost-effective gate driver solutions for motor drives and power inverters.

Packaged in a compact, surface-mountable 600V CTI SO-16 package, this full-featured and easy-to-implement gate drive optocoupler is certified to provide reinforced insulation with 2,262VPEAK working voltage meeting safety regulatory IEC/EN/DIN, UL, and CSA

https://www.broadcom.com/products/optocouplers/industrial-plastic/isolated-gate-drive-optocouplers/highly-integrated-smart-gate-drives/acpl-352j-000e

*ACPL-352J-000E*
5A Gate Drive Optocoupler with Integrated Over Current Sensing, FAULT, GATE, and UVLO Status Feedback

The ACPL-352J is a 5A gate drive optocoupler device with an integrated fail-safe IGBT and MOSFET diagnostics, protection and fault reporting. The device features common mode transient immunity (CMTI) greater than 100 kV/μs and provides minimal propagation delay with excellent timing skew. The high peak output current and wide operating voltage range eliminate the need of an output buffer circuit, enabling designers to implement cost-effective gate driver solutions for motor drives and power inverters.

Packaged in a compact, surface-mountable SO-16, this full-featured and easy-to-implement gate drive optocoupler is certified to provide reinforced insulation meeting safety regulatory IEC/EN/DIN, UL, and CSA.

https://www.broadcom.com/products/optocouplers/industrial-plastic/isolated-gate-drive-optocouplers/highly-integrated-smart-gate-drives/acpl-337j-000e

*ACPL-337J-000E*
4.0A Gate Drive Optocoupler with Integrated LED Driver, Active Miller Clamp, DESAT Detection, and Fault & UVLO Status Feedback

The Broadcom ACPL-337J is a fully featured 4.0A smart gate drive optocoupler device capable of driving high power MOSFET or IGBT directly. The device features rail-to-rail output with high current, integrated LED driver, active Miller clamp, high desaturation (DESAT) blanking current source, and Under Voltage Lock-Out (ULVO) feedback control circuit, providing a complete cost-effective gate drive solution for motor control and power inverter applications.

https://www.broadcom.com/products/optocouplers/industrial-plastic/isolated-gate-drive-optocouplers/highly-integrated-smart-gate-drives/acpl-339j-000e

*ACPL-339J-000E*
Dual-Output Gate Drive Optocoupler Interface with Integrated DESAT Detection, FAULT and UVLO Status Feedback

The ACPL-339J is an advanced 1A dual-output, easy-to-use, intelligent IGBT and Power MOSFET gate drive optocoupler interface. Uniquely designed to support MOSFET buffer of various current ratings, the ACPL-339J makes it easier for system engineers to support different system power ratings using one hardware platform by interchanging the MOSFET buffers and power IGBT/MOSFET switches. These changes can be made without redesigning the critical circuit isolation and short circuit protection. This concept maximizes gate drive design scalability for motor control and power conversion applications ranging from low to high power ratings.

#Optocouplers #SmartGateDrive #Broadcom
