Driving SiC & GaN Power Switches with Broadcom Gate Drive Optocouplers

*Driving SiC & GaN Power Switches with Broadcom Gate Drive Optocouplers*

-- More than 10A peak current.
-- More than 100kV/µs Noise Immunity.
-- Less than 100ns Propagation Delay.

https://www.broadcom.com/products/optocouplers/reference-designs/sic-mosfet

https://www.broadcom.com/products/optocouplers/reference-designs/gan-transistor

https://www.broadcom.com/products/optocouplers/industrial-plastic/isolated-gate-drive-optocouplers/highly-integrated-smart-gate-drives/acpl-355jc-000e

*ACPL-355JC-000E*
10A Gate Drive Optocoupler with Integrated FAULT Protection & Feedback in 600V CTI SO16 Package

The ACPL-355JC is a 10A gate drive optocoupler device with an integrated fail-safe IGBT and SiC MOSFET diagnostics, protection and fault reporting. The device features common mode transient immunity (CMTI) greater than 100 kV/μs and provides minimal propagation delay with excellent timing skew. The high peak output current and wide operating voltage range eliminate the need of an output buffer circuit, enabling designers to implement cost-effective gate driver solutions for motor drives and power inverters.

Packaged in a compact, surface-mountable 600V CTI SO-16 package, this full-featured and easy-to-implement gate drive optocoupler is certified to provide reinforced insulation with 2,262VPEAK working voltage meeting safety regulatory IEC/EN/DIN, UL, and CSA

https://www.broadcom.com/products/optocouplers/industrial-plastic/isolated-gate-drive-optocouplers/gate-drives/acfl-3161-000e

*ACFL-3161-000E*
10A Gate Drive Optocoupler in 600V CTI SSO12 Package

The ACFL-3161 is a 10A gate drive optocoupler device in the SSO-12 package designed for high-voltage, space-constrained industrial applications like motor drives and inverters.The new package features a 600V CTI mold which reduces the creepage requirement due to high insulation voltage in a compact footprint.

It features common mode transient immunity (CMTI) greater than 100 kV/μs, preventing erroneous gate driver failures in noisy environments. Furthermore, the new device has less than 95ns propagation delay, enabling high frequency switching to improve efficiency in driving IGBT and SiC/GaN MOSFET.

https://www.broadcom.com/products/optocouplers/industrial-plastic/isolated-gate-drive-optocouplers/gate-drives/acfj-3262-000e

*ACFJ-3262-000E*
10A Dual-Channel Gate Drive Optocoupler in 600V CTI SO-24 Package

The ACFJ-3262 is a 10A dual-channel gate drive optocoupler device in the SO-24 package designed for high voltage, space constrained industrial applications like the motor drives and inverters.The new package features 600V CTI mold which reduces the creepage requirement due to high insulation voltage in a compact footprint.

It features common mode transient immunity (CMTI) greater than 100 kV/μs, preventing erroneous gate driver failures in noisy environments. Furthermore, the new device has less than 95ns propagation delay, enabling high frequency switching to improve efficiency in driving MOSFET and GaN transistor/FET.

#Optocouplers #SiC #GaN
